Colorado River Study

Type of work: Executive project.

Executive project of the irrigation works for an area of ​​3,500 ha in the Rincón de los Sauces valley, on the right bank of the Colorado River, in a desert area 240 km from the provincial capital. • Topographic survey; • Edaphological, climatological, hydrological, geotechnical studies, etc .; • Sociological studies; • Market studies; • Determination of the most suitable agricultural units; • Economic evaluation of the project and study of its financing; • Parcel program; • Physical planning of the area; • Programming and diagramming of irrigation distribution; • Legal and administrative regime of colonization; • Executive project of the irrigation networks, storm drains and drainage, catchment work, auxiliary structures and complementary infrastructures; • General and technical specifications of the works. • Metric calculations and general budget of the works.

Oceania Building, Florida, US

Type of Work: BIM modeling and computation with scope LOD 200 of elements of the building’s facades.

The Oceania building is a 32-story multi-family building located in Sunny Isles in the city of Miami.

Urban Development in Cariló

Type of work: Master Plan and Executive Project.

The urban development is located in an area of 650 ha between Route 11 and the beach a few km south of Cariló in the jurisdiction of Villa Gesell. It includes the implementation of private lots, villages, hotel, commercial areas, sports areas, 18-hole golf course, driving, service areas, club house, gastronomy, sea club, etc. In order to complete the works, the following initial stages were proposed:

• Stage 1: Master Plan.

• Stage 2: Executive Project of the entire infrastructure: pavements, storm drains, drinking water, sewers, electricity, gas, irrigation, etc. The different disciplines were technically coordinated, including urban planning, procedures and golf course to be hired directly by the Atlántico Project S.A .; All the documentation generated was centralized and the technical file of the project was managed.

Garabí and Panambí Hydroelectric Plants

Type of Work: Preliminary project and bidding project.

The AH Garabí is located at km 863 of the Uruguay River, in the municipalities of Garruchos, Province of Corrientes, Argentina and Rio Grande do Sul in Brazil. It has an installed power of 1,152 MW. It is equipped with 8 vertical axis Kaplan-type hydrogenerators and a 22-gate spillway with an evacuation capacity of 80,066 m³ / s. The closure consists of a homogeneous dam of loose material 2,430 m long and 40.5 m high. The object of the works included the technical-economic studies and the bidding project for the construction of the works. First Stage: Preliminary Project and Second Stage: Bidding Project. The AH Panambí is located at km 1016 of the Uruguay River, in the Municipalities of Oberá, Province of Misiones, Argentina and Alecrim of Rio Grande do Sul in Brazil. An installed power of 1048 MW is estimated. It is planned to equip 7 Kaplan-type hydrogenerator groups and two weirs with 12 and 10 gates of 19.7 m wide each, with a total evacuation capacity of 81,511 m³ / s. The initial studies contemplate a concrete dam 90 m long and 34 m high. The object of the works includes the technical-economic studies and the bidding project for the construction of the works. First Stage: Preliminary Project and Second Stage: Bidding Project.

North Treatment Plant Expansion

Type of Work: Preparation of electrical projects

Carrying out 3 electrical projects including: the expansion of the 3rd Module of AySA’s North Treatment Plant, adding capacity for 300,000 inhabitants; the expansion of the “Las Catonas” Treatment Plant, increasing the capacity for 600,000 inhabitants; the Maschwitz pumping station with an inlet duct Ø greater than or equal to 500 mm; including in all: descriptive, calculation, operating memories for the automation, technical specifications, guaranteed data sheets, plans (single lines, pipes, layout), list of materials with quantities, scopes, calculations and construction deadlines and execution plan of the works.

Expansion of Av. Gral. Paz

Type of Work: Executive project and complete documentation.

Executive project and complete documentation for the remodeling of the General Paz Avenue, taking it to the category of urban highway, with total access control, in the section: “Llavallol-Santo Tomé”, length: 5.2 km. • Campaign work: topographic surveys, soundings, tests; • Executive layout project, basic works of intercoms, bridges and pavements including the designs of the slope, drains, signaling, design of the protection and security elements; • Computations and budgets. Complementary specifications.

Drinking water around the Mar Chiquita Lagoon

Type of Work: Basic studies, Executive Project, Descriptive and Technical Report, Calculation and Budget, Preparation of Specifications and Technical Specifications for Bidding.

– BIM modeling with LOD 200 scope of drinking water, sewage, and stormwater networks.

– 3D coordination and interference analysis.

Executive Projects for Storm Drains (D), Sewage (S) and Provision of Potable Water (W), in the Towns of: Balnearia (WSD-6105 inhab), Brinkmann (SD-9890 inhab), Miramar (WD-2023 inhab) , Morteros (W-16890 inhab), Cnia 10 de Julio (D-73 inhab), Cnia San Pedro (WS-106 inhab), Cnia Vignaud (S-722 inhab), La Paquita (S-947 inhab), La Para (WD-3404 inhab), in the Province of Córdoba and Ceres (D-14499 inhab) in the province of Santa Fe.

Miami Cruise Terminal, Florida, US

Type of Work: Calculation of elements of the building’s facades, from a BIM Model made by third parties.

The cruise terminal, belonging to an important naval line, will have the possibility of receiving two large vessels simultaneously, while the terminal will have a capacity of 28,000 people.

Dulce river

Type of work: Executive project and general and special technical specifications for the call for bids for the Río Dulce project, Subproject IV (1st stage, 16,000 ha).

Executive project and general and special technical specifications for the call for bids for the Río Dulce project, Subproject IV (1st stage, 16,000 ha). • Technical-economic feasibility study for the rehabilitation of the San Martín Canal in one of its two routes; • Mathematical model for the optimization of irrigation and drainage networks that, for different possible layouts, allows selecting the one with the best design and the greatest economy of soil movement and works of art; • Executive project of the irrigation networks and storm drains and drainage, with a length of approximately 500 km; • Executive project of the works of art for the irrigation and drainage canals; • Stakeout on the ground of all canals and works of art; • Mathematical model for the design of irrigation and drainage networks for detailed hydraulic calculation and metric calculations section by section; • General and technical specifications of the works; • Metric calculations and general budget of the works.
