Engineering studies at the final project level for mitigation works on the El Potrero stream, verifying the stream’s comprehensive operation with port works at the Punta del Este Marina.

  • Client

    Chihuahua Club S.A.

  • Country

    Uruguay

  • Location

    Punta del Este

  • Area

    Hidráulica – Desarrollo Urbano

  • Year

    2014

Type of Work: Hydrological and hydraulic study of the El Potrero River and flood protection and/or mitigation works

Update of the hydrological and hydraulic studies of El Potrero Creek in Portezuelo Bay, from the Laguna del Sauce Control Works to its mouth at the site of the future port works for the Punta del Este Marina. The studies determined a baseline for El Potrero Creek without any works and the influence of the proposed marina works on its operation, analyzing alternative works to mitigate the effects of flooding on neighboring properties. The selected alternative was developed at the Final Project level, contemplating the construction of 1,700 m of riparian barriers with mattresses.

Amount of consulting services: US$56,440.

Port Works Marina Punta del Este – Stage I

  • Client

    Chihuahua Club S.A.

  • Country

    Uruguay

  • Location

    Punta del Este

  • Area

    Hidráulica – Desarrollo Urbano

  • Year

    2014

Type of Work: Engineering Study, Layout Alternatives Analysis, Final Port Works Project

The port works for the Punta del Este Marina near El Potrero Creek, between Punta Ballena and Punta Rasa, in Uruguay, were developed by Latinoconsult in 1990. The layout modifications were carried out, for reasons beyond the control of Chihuahua Club S.A., which necessitated amending the original project. These significant changes had to be evaluated; therefore, a series of layout alternatives were analyzed to achieve acceptable internal unrest within the port area and develop the selected layout at the Final Project Level. This included the engineering of the riverbank defenses consisting of 2,530 m of sheet piling and 500 m of breakwaters.

Amount of consulting services: US$176,237.

Gral Belgrano water plant inspection

Previous
Next

  • Client

    AySA

  • Country

    Argentina

  • Location

    Buenos Aires Province

  • Area

    Water Management

  • Year

    2022 – 2025

Type of Work: construction inspection.

Execution of a pumping basin, the construction of a chamber and bypass conduit, a connection chamber and a suction chamber with provision and assembly of 3 electric pumps of 6 m³/sec, with all the necessary electromechanical installation for its operation and the respective industrial warehouse.

In addition, an underground conduit to a future partitioning chamber.

Water Plant Inspection in Salta

Previous
Next

  • Client

    Secretaría de Infraestructura y Política Hídrica del Ministerio de Obras Públicas

  • Country

    Argentina

  • Location

    Salta Province

  • Area

    Water Management – Environment- Urban Development

  • Year

    2022 – 2026

Type of Work: Work inspection; Detail engineering review.

The work consists of an expansion of the existing plant that will increase its processing capacity from 2,600 m³/h to 5,000 m³/h.

A new module will be built that includes screens, sand removal, a lifting station, primary settlers, trickling beds with a stone mantle, secondary settlers, chlorine gas dosing, contact chamber, and drainage to the Arenales River.

Exploratory surveys for Aysa, Buenos Aires

  • Client

    AYSA

  • Country

    Argentina

  • Location

    Buenos Aires Province

  • Area

    Water Management

  • Year

    2022 – 2023

Type of Work: Work Inspection Support Services – Exploration surveys and Exploitation drilling.

A number of Geologists are under the guidance of AySA to carry out inspection tasks of the works in the Province of Buenos Aires, carrying out the technical and administrative control of the water exploration and exploitation works.

The entire staff is supervised and managed by AySA.

Technical inspection of drains, Santiago del Estero

  • Client

    Secretaría de Infraestructura y Política Hídrica del Ministerio de Obras Públicas

  • Country

    Argentina

  • Location

    Santiago del Estero Province

  • Area

    Water Management

  • Year

    2022 – 2026

Type of Work: Technical and environmental inspection. Review of the Executive Project and Detail Engineering.

The Work consists of: Home collector networks and Main collectors: 131,265 m of PVC-RCPD pipes of 160, 200, 315, 355, 400, 500 and 630 mm will be laid; Elevating station for sewage liquids and drive pipe. The EELC is a cylindrical tank of ø 6 m and 10 m deep; 3 electric pumps of 30 kW each, ductile iron pipe that connects to a manifold, valves, gate and bars.

Sewage treatment plant: with pretreatment to reduce solids in suspension, consisting of an arrival chamber, a channel of approx., bars to stop coarse material, a sand trap to retain inorganic solids, a degreaser, a spillway, a Parshall gutter and a distribution chamber for flows to lagoons.

Stabilization ponds: anaerobic, facultative, maturation ponds.

Disposal of treated liquids in the receiving body: the final discharge of the treated effluent will serve to irrigate inedible forest species located on the property, if there are surpluses to a drainage channel that carries the water to the Salado River.

Costa Urbana Development, Buenos Aires

Previous
Next

  • Client

    IRSA

  • Country

    Argentina

  • Location

    City of Buenos Aires

  • Area

    Urban Development – BIM

  • Year

    2022

Type of Work: Pre-feasibility study, infrastructure design, technical support.

Costa Urbana is an undertaking to be developed in an area of 71.6 hectares located southeast of the current Puerto Madero. It is an open neighborhood that will be integrated into the Autonomous City of Buenos Aires.

Approximately 2/3 of the area will be ceded by the developer IRSA to the City and where a new public park will be created. In the remaining area, more than 895,000 m2 will be built for various uses: homes, offices, shops, services, public spaces, education, entertainment, among others.

Oceania Building, Florida, US

  • Client

    Private Client

  • Country

    United States of America

  • Location

    Florida State

  • Area

    Urban Development – BIM

  • Year

    2022

Type of Work: BIM modeling and computation with scope LOD 200 of elements of the building’s facades.

The Oceania building is a 32-story multi-family building located in Sunny Isles in the city of Miami.

“W” Hotel, Florida, US

  • Client

    Private client

  • Country

    United States of America

  • Location

    Florida State

  • Area

    Urban Development – BIM

  • Year

    2021

Type of Work: BIM modeling and computation with scope LOD 200 of elements of the building’s facades.

The hotel is located a few kilometers from the commercial center of Miami, on Bizcayne Bay.

Master plan “Proyecto San Martín”

Render proyecto

  • Client

    IRSA

  • Country

    Argentina

  • Location

    Pcia. de Buenos Aires

  • Area

    Urban Development

  • Year

    2021-2022

Type of Work: Technical feasibility study of infrastructure, negotiations with companies providing services and development of the Bidding Preliminary Project.

The scope includes the execution of the Infrastructure Preliminary Project and the Bidding Project for the trunk networks that make up the macro-blocks of the San Martín Urbanization Project, as well as the complete management of Feasibilities of services for the Master Plan. The project of the following specialties is included: Potable Water, Sewage Drains, Storm Drains, Electrical Network, Lighting and Weak Currents, Gas, Road Geometric Design and Pavements.
