Metrobús 9 de Julio Av. distributor

Previous
Next

  • Client

    Autopistas Urbanas S.A. (AUSA)

  • Country

    Argentina

  • Location

    City of Buenos Aires

  • Area

    Transportation

  • Year

    2014-2016

Type of Work: Review and approval of the Executive Project, and Inspection of the work, including works to remove interference from public services and temporary traffic diversions.

Reversal of the direction of movement of the guided lanes at different levels (tunnels of 491 m and 493 m), and crossing the tunnel under Av. San Juan until it connects with the intermodal transfer station in Plaza Constitución. The work includes reviewing the Contractor’s socio-environmental Management Plan and monitoring its implementation.

Formosa Treatment Plant

  • Client

    Ministerio de Planificación, Inversión, Obras y Servcios Públicos-Unidad Central de Administración de Programas (U.C.A.P.)

  • Country

    Argentina

  • Location

    Pcia. de Formosa

  • Area

    Water Management

  • Year

    2014-2022

Type of Work: Technical and environmental inspection.

The Work consisted of the construction of a Sewage Treatment Plant on the southern defense of the City of Formosa, for a population of 184,000 inhabitants, whose treated effluent will be propelled to the Riacho Oro, some 2,600 m distant, with a pipeline over the defense itself. Project flows at 10 years are 0.554 m³ / sec and at 20 years, 0.93 m³ / sec. The hydroelectromechanical work has 6,235 m³ of concrete. The Consultant developed all the necessary technical and administrative activities to ensure that the Contractor will execute the works effectively complying with the stipulations contained in their respective Contract, in the designs and in the Specifications. The work included the review of the Contractor’s socio-environmental Management Plan and the monitoring of its implementation.

Drinking Water in Wichí

Previous
Next

  • Client

    Unidad Coordinadora de Programas con Financiación Externa (U.C.P.F.E.) – Proyecto de Infraestructura Hídrica del Norte Grande

  • Country

    Argentina

  • Location

    Pcia. de Chaco

  • Area

    Water Management

  • Year

    2014-2022

Type of Work: Project Review and Construction Supervision.

The purpose of the work is to satisfy the demand for drinking water in a large area in the north of the Province of Chaco called “El Impenetrable”. The works to be carried out are: – Capture in the Bermejo River by means of a floating pontoon in the Pintado; – Raw water conduction until pre-treatment 90 m pipe A ° Ø 500 mm; – Aqueduct of pre-sedimentation water to Wichí HDPE D. 500 mm, length 7,713 m; – Elevator Station to the treatment plant in Wichí and to the Nueva Pompeya Mission, pumping capacity: 0.77 m³ / sec; – Treatment plant with slow filters in Wichí to supply Wichi and El Sauzal and complementary works. The hydroelectromechanical work has 13,500 m³ of concrete. The work includes reviewing the Contractor’s socio-environmental Management Plan and monitoring its implementation.

Urban Public Transport in the City of Corrientes

Previous
Next

  • Client

    PTUMA - Proyecto de Transporte Urbano para Areas Metropolitanas - Ministerio del Interior y Transporte

  • Country

    Argentina

  • Location

    Pcia. de Corrientes

  • Area

    Transportation

  • Year

    2015-2017

Type of Work: Direction and general coordination of the project, elaboration of the executive projects of the works.

Review of the conceptual design prepared in 2010 and adjusted in 2014. Preparation of the executive project for the construction of the Chacabuco transfer station, intermediate stations, exclusive lanes for public transport on Av. 3 de Abril and preferential lanes in the central area. The work includes a socio-environmental impact study.

Bolivia-Argentina Border Interconnection Line – T.S. Tartagal – T.S. Pichanal – T.S. San Juancito at 500 kV

Previous
Next

  • Client

    Ende Transmisión S.A.

  • Country

    Argentina

  • Location

    Pcias. de Salta y Jujuy

  • Area

    Energy

  • Year

    2016

Type of Work: Preparation of Basic Project and bidding documentation.

The works consisted of: an extra-high voltage line of approx. 290 km in length, at 500 kV, between the towns of Tartagal (Salta) and San Juancito (Jujuy); a 500 kV transformer station (300 MVA) in the town of Pichanal (Salta) and an extension of the existing 500 kV transformer station in San Juancito (Jujuy).

New headquarters of the General Archive of the Nation

Previous
Next

  • Client

    Programa de Modernización del Archivo General de la Nación

  • Country

    Argentina

  • Location

    City of Buenos Aires

  • Area

    Urban Development

  • Year

    2016-2021

Type of Work: Technical Supervision and Inspection of the construction of the work.

Construction Supervision Service for the Construction of the New Headquarters of the General Archive of the Nation, whose property is included between Pichincha streets, November 15th of 1889, Pasco and Rondeau extension.

Renovation of Belgrano Railway – Sections V and VI

Previous
Next

  • Client

    ADIF - Administración de Infraestructuras Ferroviarias Sociedad del Estado

  • Country

    Argentina

  • Location

    Pcia. de Chaco

  • Area

    Transportation

  • Year

    2017-2020

Type of Work: Review of Executive Project and Inspection of works.

The main tasks carried out in the Supervision were: cleaning of the section and conditioning of channels and sewer beds; auscultation of existing rails; removal of existing track; conformation of the new subgrade and cross-sectional profile of the track zone; assembly and placement of the new narrow gauge track structure; provision and watering of stone ballast and its compaction; renovation, rehabilitation and overhaul of track devices; renewal of Level Crossings; Reconditioning of used rails for reuse and total renovation of culverts. The work included the monitoring of the Environmental Management Plan and the control of hygiene and safety in the contractor’s work.

North Treatment Plant Expansion

  • Client

    AySA - Aguas y Saneamientos Argentinos

  • Country

    Argentina

  • Location

    Pcia. de Buenos Aires

  • Area

    Water Treatment

  • Year

    2017-2018

Type of Work: Preparation of electrical projects

Carrying out 3 electrical projects including: the expansion of the 3rd Module of AySA’s North Treatment Plant, adding capacity for 300,000 inhabitants; the expansion of the “Las Catonas” Treatment Plant, increasing the capacity for 600,000 inhabitants; the Maschwitz pumping station with an inlet duct Ø greater than or equal to 500 mm; including in all: descriptive, calculation, operating memories for the automation, technical specifications, guaranteed data sheets, plans (single lines, pipes, layout), list of materials with quantities, scopes, calculations and construction deadlines and execution plan of the works.

Derivation weir in Santiago del Estero

Previous
Next

  • Client

    Ministerio de Obras Servicios Públicos y Medio Ambiente – Subsecretaría del Agua de la Pcia. de Santiago del Estero

  • Country

    Argentina

  • Location

    Pcia. de Santiago del Estero

  • Area

    Hydraulics

  • Year

    2017-2022

Type of Work: Technical inspection.

The works built, located about 3 km downstream from the border with the Province of Salta, in the area called Cruz Bajada, included the execution of a weir over the Salado River, a sand trap, a fish ladder, an intake that allowed the diversion of from the river a flow of 18 m³ / s feeding the Link Channel (0.5 km long) to the distributor node of flows and, from the latter, to the section that was built of the Canal de Dios (22.8 km long ).

Chaco – Corrientes Bridge

Previous
Next

  • Client

    Dirección Nacional de Vialidad (DNV)

  • Country

    Argentina

  • Location

    Pcias. de Chaco y Corrientes

  • Area

    Transportation

  • Year

    1968-1974

Type of Work: Project review and construction supervision.

At the time of its construction, this bridge, reinforced with precast and post-tensioned concrete girder-box elements, was considered the longest in South America. It is a communication route more than 1,600 m long, which crosses the Paraná River, and which has been of fundamental importance for the economic and social relations of the Chaco and Corrientes provinces. The tasks carried out were the review of the preliminary project and assistance in the selection of the contractor. Preparation and supervision of the complementary research program. Executive project of the bridge and accesses (1,670 m of bridge and 1,131 of viaducts. Construction supervision).
